Cement Feeding Machine

Cement Feeding Machine
Cement Feeding Machine
Product Code : 02
Product Description

Cement Feeding Machine

With the support of our highly experienced and skilled workforce, we are renowned as one of the well equipped manufacturers, suppliers & exporters of Cement Feeding Machine. These feeding machines are exported overseas due to large demand in the foreign market. Our offered range of cement machines finds its wide application in construction industry. Cement Feeding Machine is tested on various parameters by our team of quality analyst on various predefined parameters. Our offered machines are widely known for their features such as durability, minimum maintenance and robust construction.



Further Details:

Cement Feeding Machine Umiya Screw Pumps are constructed of mild and structural steel, and mounted on a base. Umiya pumps are equipped with pedestal blocks that support a pump screw which helps to provide a smooth, balanced operation. The screw is dynamically balanced and areas of this screw, along with other parts of the pump in direct contact with the material to be conveyed, are made of hardened, wear-resistant material and special hard surfacing where required. The screw is directly coupled to the driving motor but can be v-belt driven.

MODEL - UMIYA -I & UMIYA-II DESCRIPTION It is the most versatile and speedy method of transferring bulk material from one point to another within a defined area. APPLICATIONS The Ritesh Screw Pumps are heavy-duty, screw-type pneumatic pumps. These pump systems are most commonly used to convey dry, free-flowing, pulverized materials from grinding mills, transfer materials from silo to silo, transfer dust from collectors, and load and unload railcars, ships and barges. The materials are conveyed literally anywhere a pipeline can be run and to any number of delivery points. OPRATION The materials to be conveyed enter the hopper by gravity or dumped by any means. The material is compacted as it is advanced.

Its density is further increased in the space between the terminal flight of the screw and the face of the non-return valve to form a seal against the transport line pressure, thus preventing blowback. The material then enters the discharge body, is fluidized by compressed air, and is conveyed into the transport line. FOLLOWING ACCESSORIES INCLUDED Suction Silencer Non Return Valve Discharge Silencer V-Belt Set Spring Loaded safety Valve V- Belt Guard Pressure gauge Drive Pulley Suction Filter Driven Pulley TECHNICAL SPECIFICATIONS SR. ITEM DESCRIPTION SPECIFICATION 01 Model Umiya-I Umiya-II 02 Output Capacity* 12-15 TON/HR 20-25 TON/HR 03 Feed Hopper Capacity 500 Kg 700 Kg 04 Screw TOUGHEND TOUGHEND 05 Screw Motor 22.5 kW / 30 HP 22.5 kW / 30 HP 06 Twin Lobe Air Blower PI-19 PI-22 07 Blower Motor 30 kW / 40 HP 37.5 kW / 50 HP 08 Struture WITH WHEEL/ANTI VIBRATION PAD WITH WHEEL/ANTI VIBRATION PAD 09 Power Supply 415 V AC + 10%, 3 PHASE, 50 HZ + 5%.

GENERAL SPECIFICATIONS Umiya Screw Pumps are constructed of mild and structural steel, and mounted on a base. Umiya pumps are equipped with pedestal blocks that support a pump screw which helps to provide a smooth, balanced operation. The screw is dynamically balanced and areas of this screw, along with other parts of the pump in direct contact with the material to be conveyed, are made of hardened, wear-resistant material and special hard surfacing where required. The screw is directly coupled to the driving motor but can be v-belt driven. Standard equipment on Umiya pumps includes a pressurized seal and bearing assembly that extends the service life of the discharge seals by preventing the material being handled from entering the bearing area. Each pump system includes the pump, drive motor and compressed air source.
